Slitting saw and knives - production, service

Slitting saw CSN 222910

Materials: steel, cast, non-ferrous metals, plastic
Application: recommended for slotting the fragile and hard materials which make short chips, suitable for cutting thin-walled profiles
Machine: metal processing machines
Characteristic:

  • HSS circular saw blades with rought teeth
  • hollow ground with flange, standardly produced without driving pin holes and without groove
  • tooth form A (by request AW)
  • the cutting edge is very sharp; the chip clearance is reduced and it can´t remove longer chips away from the cutting area efficiently
  • hollow ground according DIN 1840

High quality slitting saw ČSN 222910, designed especialy for high performance. Slitting saws produced in Europe - Czech Republic.



The saw blades ČSN 222910 with fine teeth and teeth form A are recommended for slotting the fragile and hard materials. The teeth form A is suitable especially on the thin saw blades with tooth pitch from 0,8 mm to 3,0 mm. The cutting edge is very sharp. The chip clearance is reduced and it cannot remove longer chips away from the cutting area efficiently. In standard modification the saw blades are made with taper ground without flange. They can be ordered with flange which is good for their stabilization, with driving pin holes or with groove and teeth form AW (the teeth form A with alternate chamfering).



HSS - circular saw blades for metal CSN 222910 - f ine teeth, tooth form A

D (mm) 20 25 32 40 50 63 80 100 125 160 200 225 250 275 315
dH7 (mm) 5 8 8 10 13 16 22 22 22/27 32 32 32 32 32 32/40
B (mm) number of teeth
0,20 mm 80 80 100 128 128
0,25 mm 64 80 100 100 128 160
0,30 mm 64 80 80 100 128 128 160
0,40 mm 64 64 80 100 100 128 160
0,50 mm 48 64 80 80 100 128 128 160
0,60 mm 48 64 64 80 100 100 128 160 160
0,80 mm 48 48 64 80 80 100 128 128 160
1,00 mm 40 48 64 64 80 100 100 128 160 160 200
1,20 mm 40 48 48 64 80 80 100 128 128 160 200
1,60 mm 40 40 48 64 64 80 100 100 128 160 160 180 200
2,00 mm 32 40 48 48 64 80 80 100 128 128 160 180 200 220
2,50 mm 32 40 40 48 64 64 80 100 100 128 160 140 160 200 200
3,00 mm   32 40 48 48 64 80 80 100 128 128 140 160 200 200
3,50 mm   32 40 48 48 64 80 80 100 128 128 140 160 160 200
4,00 mm     40 40 48 64 64 80 100 100 128 140 160 160 160
4,50 mm     40 40 48 64 64 80 100 100 128 140 160 140 160
5,00 mm       40 48 48 64 80 80 100 128 128 128 140 160
5,50 mm       40 48 48 64 80 80 100 128 128 128 140 160
6,00 mm         40 48 64 64 80 100 100 114 128 140 160



HSS slitting saws coarse with Coarse Pitch as to DIN 1838 Toothform B. Used for medium deep cutting and cut-off operations. Hollow ground on both sides to prevent binding.

D (mm) 3/4 1" 1 1/4 1 1/2 2"
dH7 (mm) 1/4 1/4 3/8 3/8 3/8
B (mm) number of teeth
0,006 40 50 60 72 100
0,008 40 50 60 72 100
0,1 40 50 60 72 100
0,01 40 50 60 72 100
0,012 40 50 60 72 100
1/6 4 40 50 60 72 100
0,02 40 50 60 72 100
0,025 40 50 60 72 100
1/3 2 40 50 60 72 100
3/6 4 40 50 60 72 100
1/1 6 40 50 60 72 100
5/6 4 40 50 60 72 100
3/3 2 40 50 60 72 100
7/6 4 40 50 60 72 100
1/8 40 50 60 72 100
5/3 2       72 100
3/1 6       72 100
7/3 2         100
1/4         100



Non-binding request - Slitting saw CSN 222910

Dear customer, you have the opportunity to make a preliminary request for this product. In the inquiry basket you can specify your product requirements according to the table, or you can enter any questions for the sales representative. The sales representative will contact you as soon as possible.
