Slitting saw and knives - production, service

Slitting saw CSN 22 2916

Materials: steel, cast, non-ferrous metals
Application: recommended for deep slotting and cutting materials which make longer chips, suitable for cutting thick-walled profiles (wall over 2,5 mm)
Machine: metal processing machines
Characteristic:

  • HSS circular saw blades with rought teeth
  • hollow ground with flange, standardly produced without driving pin holes and without groove
  • tooth form B (by request BW)
  • the chip clearance is not as much reduced as in case of fine teeth A and it allows to put  chips away more efficiently
  • the tolerances and hollow ground according CSN 222916



High quality slitting saw ČSN 222913 half-rought teeth, designed especialy for high performance. Slitting saws produced in Europe - Czech Republic.

CSN 222916 saw blades with rough teeth and tooth form B are very efficient for cutting steel materials. In comparison with tooth form A there is much larger area for removing chips and that is why they enable bigger cut. They can be ordered with tooth form BW (tooth form B with alternate chamfering).



HSS - circular saw blades for metal CSN 222916 - rough teeth, tooth form B

D (mm) 20 25 32 40 50 63 80 100 125 160 200 225 250 275 315
dH7 (mm) 5 8 8 10 13 16 22 22 22/27 32 32 32 32 32 32/40
B (mm) number of teeth
1,00 mm           40 40 52 64 80
1,20 mm           32 40 50 64 64 80
1,60 mm           32 40 50 50 64 80 80 80
2,00 mm           32 32 40 50 64 64 80 80 100
2,50 mm           32 32 40 50 50 64 64 80 80 80
3,00 mm           24 32 40 40 50 64 64 64 80 80
3,50 mm           24 32 40 40 50 64 64 64 80 80
4,00 mm           24 26 32 40 50 50 50 64 80 80
4,50 mm           24 26 32 40 50 50 50 64 84 80
5,00 mm           24 26 32 40 40 50 50 64 64 64
5,50 mm           24 26 32 40 40 50 50 64 64 64
6,00 mm           20 26 32 32 40 50 50 50 50 64



HSS slitting saws coarse with Coarse Pitch as to DIN 1838 Toothform B. Used for medium deep cutting and cut-off operations. Hollow ground on both sides to prevent binding.

D (mm) 2 1/2 3" 3 1/2 4" 4" 4 1/2" 5" 5" 6" 6" 7" 7" 8" 8" 10" 10" 12" 12"
dH7 (mm) 1" 1" 1" 1" 1 1/4" 1" 1" 1" 1 1/4" 1 1/4" 1" 1 1/4" 1" 1 1/4" 1" 1 1/4" 1" 1 1/4"
B (mm) number of teeth
1/6 4 26 30
1/3 2 26 30 32 36   38 40   44 44
3/6 4 26 30 32 36   38 40   44
1/1 6 26 30 32 36 36 38 40 40 44 44 48   52 52 62 62
5/6 4 26 30 32 36 36   40   44   48 48 52 52 62
3/3 2 26 30 32 36   38 40 40 44 44 48 48 52 52 62 62
7/6 4 26 30 32 36         44
1/8 26 30 32 36 36   40 40 44 44 48 48 52 52 62 62 70 70
5/3 2   30 32 36     40   44 44 48   52   62
3/1 6 26 30 32 36     40   44 44 48   52 52 62   70
7/3 2   30 32 36 36   40   44   48   52   62
1/4 26 30 32 36     40   44 44   48 52 52 62



Non-binding request - Slitting saw CSN 22 2916

Dear customer, you have the opportunity to make a preliminary request for this product. In the inquiry basket you can specify your product requirements according to the table, or you can enter any questions for the sales representative. The sales representative will contact you as soon as possible.
